Power Tong

power tong features high-efficiency, safety, reliability, labor saving, and ensures connection quality. Tong head is designed as open type and equipped with advanced swing-type double jaw assembly, which can secure reliable clamping.

Description

Tubing Power Tong

⊙They are designed and manufactured according to SY/T5074.

⊙power tong features high-efficiency, safety, reliability, labor saving, and ensures connection quality.


Drill Pipe Power Tong

⊙They are designed and manufactured according to SY/T5074.

⊙power tong features high-efficiency, safety, reliability, labor saving, and ensures connection quality.


Casing Power Tong

⊙They are designed and manufactured according to SY/T5074.

⊙power tong features high-efficiency, safety, reliability, labor saving, and ensures connection quality.

Specifications

XQ140/12Y hydraulic power tong

Applicable range:2.3/8"~5.1/2"

XQ140/12Y hydraulic power tong
Applicable range:2.3/8"~5.1/2"
Max.torque:8850ft.lbf
Speed:14-72rpm
Rated pressure:1750psi
Max flow:32gpm
XQ114/6YBhydraulic power tong

XQ114/6YB hydraulic power tong

Applicable range:2.3/8"~4.1/2"

Applicable range:2.3/8"~4.1/2"
Max.torque:4425ft.lbf
Speed:20-85rpm
Rated pressure:1595psi
Max flow:26gpm
XQ89/3YChydraulic power tong,

XQ89/3YC hydraulic power tong

Applicable range:2.3/8"~3.1/2"

Applicable range:2.3/8"~3.1/2",
Max.torque:2213ft.lbf,
Speed:30-90rpm,
Rated pressure:1450psi,
Max flow:21gpm

ZQ127-25 drill pipe power tong

Applicable range:2 3/8"-3 1/2"

ZQ127-25 drill pipe power tong
Applicable range:2 3/8"-3 1/2"
Max.torque:18440 ft.lbf
Speed:10.5-65rpm
Pressure rating:1740 psi
Flow rating:120l/min

ZQ203-100drill pipe power tong

Applicable range:3 1/2"-8"

ZQ203-100 drill pipe power tong
Applicable range:3 1/2"-8"
Max.torque:73750  ft.lbf
Speed:2.7-40rpm
Pressure rating:2400 psi
Flow rating:114 l/min

ZQ162-50Ⅱdrill pipe power tong

Applicable range:2 3/8"-5"

ZQ162-50Ⅱ drill pipe power tong
Applicable range:2 3/8"-5"
Max.torque:36880 ft.lbf
Speed:4.1-60rpm
Pressure rating:2320 psi
Flow rating:120 l/min

ZQ203-125Ⅱdrill pipe power tong

Applicable range:3 1/2"-8"

ZQ203-125Ⅱ drill pipe power tong
Applicable range:3 1/2"-8"
Max.torque:92200  ft.lbf
Speed:2.7-40rpm
Pressure rating:3000 psi
Flow rating:114 l/min

TQ178-16Y hydraulic casing  tong

Applicable range:4"-7"

TQ178-16Y hydraulic casing  tong
Applicable range:4"-7"
Max pressure:2610 psi,
Working flow:120-160 l/min
Max torque:11820ft.lbf
Speed:9-79rpm

TQ340-35Y2 hydraulic casing  tong

Applicable range:4 1/2"-13 3/8"

TQ340-35Y2 hydraulic casing  tong
Applicable range:4 1/2"-13 3/8"
Max pressure:2900psi
Working flow:110-170l/min
Max torque:27285ft.lbf
Speed:8-90rpm

TQ356-55Y hydraulic casing  tong

Applicable range:4 1/2"-14"

TQ356-55Y hydraulic casing  tong
Applicable range:4 1/2"-14"
Max pressure:3000psi
Working flow:110-170l/min
Max torque:40560ft.lbf
Speed:4.8-61rpm

TQ508-70Y hydraulic casing  tong

Applicable range:9 5/8"-20"

TQ508-70Y hydraulic casing  tong
Applicable range:9 5/8"-20"
Max pressure:2900psi
Working flow:140-220l/min
Max torque:51600ft.lbf
Speed:4.6-48rpm
