Description

Features

⊙Special repair kit is available for easy maintenance.

⊙Key components adopt hard alloy to increase service life.

⊙Surfaces vulnerable to abrasion are handled by special technology.

Specifications

Rated Working Pressure	69.0MPa~138.0Mpa(10,000psi~20,000psi)
Nominal Size	2″, 3″
Temperature Rating	-29℃~121℃(PU), -46℃~121℃ (LU)	-20℉~250℉ (PU),-50℉~250℉(LU)
Service	Standard, Sour Gas
Application	Fracturing, Cementing, Acidizing, Testing Lines

Photo Gallery

Data Download
