Stationary Gas Turbine Genset

Jereh provides stationary gas turbine generator sets with a power range of 5MW to 50MW, suitable for both simple-cycle and combined-cycle power plants. The units are applicable for power supply to utility grids, microgrids, industrial and mining facilities as well as data center, and can also serve for grid peak shaving.

Description

Advantages

• A diverse of portfolio

specialize in small to mid-sized gas turbines (5–50MW), offering a wide range of Genset.

• Innovative Integration technology

Leveraging our experience in mobile generator sets, we excel in modular design, lightweight construction, intelligent monitoring, and grid-parallel management, enabling us to tailor solutions through technical innovation.

• Turnkey Capability

Our capabilities include simple cycle gas turbine generator sets, Combined cycle power plant development, equipment upgrade, and subsystem development—delivering comprehensive one-stop turnkey solutions to our clients.

Intelligent Power Solution

Primary Power Solutions

Jereh provides data centers with continuous, high-efficiency primary power or peaking power by smart power distribution and flexible dispatch across different energy resources, while leveraging efficient variable frequency drives and intelligent control systems, significantly improving energy utilization, reducing PUE, ensuring grid stability, uninterrupted operations and cost efficiency.

Backup Power Solutions

Equipped with high-capacity, fast-response generation systems (such as gas turbine plus storage), Jereh enables seamless millisecond switching during grid failures, ensuring uninterrupted, robust power for critical data center loads and safeguarding data security and business continuity.

Distributed Energy

Jereh adaptively deploys distributed energy solutions to meet user requirements, leveraging cascading energy use and efficient supply to enhance reliability, safety, and cost-effectiveness.

Specifications

Model JTS6 JTS8 JTS18 JTS25 JTS35
Power 5.8MW 8MW 17.2MW 24MW 33.8MW
Fuel Type Natural Gas /Liquid Fuel/Dual-Fuel/Other Fuels
Efficiency 33.1% 34.3% 37% 37.5% 39.5%
Heat Rate 10,889kJ/kWh 10,500kJ/kWh 9,722kJ/kWh 9,595kJ/kWh 9,104kJ/kWh
Voltage 13.8/11kV
Frequency 60/50Hz
NOx Emission ≤25ppmv 15%O₂(DLE) ≤ 15 ppmv 15%O₂ (9.9 ppm optional) 15/9ppmv 15%O₂(DLE) ≤25ppmv 15%O₂(DLE)
Note:


1)   The generated power is based on ISO condition, with gas fuel LHV 47.5MJ/kg.

2)   The International Organization for Standardization(ISO) has defined the following standard conditions:

•  Ambient Temperature:15℃.

•  Barometric Pressure:101.3kPa.

•  Relative Humidity:60%.

•  Inlet Exhaust Losses:None.

For detailed information, please consult Jereh's engineers.
