Drilling Fluid Additives

With abundant accumulation of application experience, JEREH develops itself designing and engineering ability, to provide cost-effective drilling fluids systems and additives.

Description

Fluid Loss Control Additives—PAC-HV

D-FL-FILTROL-HV is a uniquely modified metal-cellulose polymer(PAC) engineered specifically to maintain a low, stable fluid loss while providing secondary inhibition of reactive shale and a higher viscosity profile. D-FL-FILTROL-HV provide superior wellbore stability, better cuttings integrity, improved solids control and lower drilling costs and fit for all water-base mud system.

Packing and Storage

⊙25Kgs pre Ply Kraft Paper Bag.

⊙Keep Storing in dry and well-ventilated area. Keep container closed. Keep away from heat, sparks and flames. Keep away from incompatibles.

⊙Follow safe warehousing practices regarding palletizing, shrink-wrapping and stacking.


Fluid Loss Control Additives—PAC-LV

D-FL-FILTROL-ULV ultra-low-viscosity polymer is a high-performance, modified cellulosic polymer designed to provide cuttings encapsulation and filtration control in water-base drilling fluids, ranging from freshwater to saturated saltwater. D-FL-FILTROL-ULV additive provides improved shale control and is primarily used in weighted systems to avoid an uncontrollable viscosity build-up.

Packing and Storage

⊙25Kgs pre Ply Kraft Paper Bag.

⊙Keep Storing in dry and well-ventilated area. Keep container closed. Keep away from heat, sparks and flames. Keep away from incompatibles.

⊙Follow safe warehousing practices regarding palletizing, shrink-wrapping and stacking.


Xanthan Gum-- UNIVIS-TEC

UNIVIS-TEC Xanthan gum is a dispersible, a rapidly mixing, non-clarified, high-molecular weight biopolymer used to increase viscosity in water-base base drilling fluid systems. With the unique ability of producing a fluid that is highly shear-thinning and thixotropic, by small dosage ratio, it provides viscosity and weight material suspension for all water-base mud systems.

Packing and Storage

⊙25Kgs pre Ply Kraft Paper Bag

⊙Keep Storing in dry and well-ventilated area. Keep container closed. Keep away from heat, sparks and flames. Keep away from incompatibles.

⊙Follow safe warehousing practices regarding palletizing, banding, shrink-wrapping and stacking.


API Premium Bentonite-- VF-21

The VF-21 Permium Bentonite also aids in filter-cake formation and filtration control. It has proven effective in drilling, coring, workover and completion fluids. Good agitation and sufficient shear could be easily get when build fresh mud by VF-21. It is also effective in specialty applications of casing packs, packer fluids and spotting fluids, etc. The amount of VF-21 rheology modifier required depends upon the type of organic system and the degree of thickening or other properties desired. Addition levels are typically between 20-35 kg/m3 based on the total formulation weight. For maintenance, VF-21 could maintain the flow properties and gel strengths in the desired ranges. In packer fluids and casing packs, typically range in the 20 to 40 lb/bbl (57.3 to 114.6kg/m3).

Packing and Storage

VF-21 is packaged in 50-lb (22.7-kg)/ 55-lb (25-kg), multi-wall, paper sacks.

Store in a dry, well-ventilated area. Keep container closed. Store away from incompatibles. Follow safe warehousing practices regarding palletizing, banding, shrink-wrapping and/or stacking.


Barite—WA-01.

WA-01 API 13A Barite with Insoluble, chemically inert and nontoxic properties exceeds the API specifications. And used as weight agent to increase the density of both oil based and water based mud. In rotary drilling of oil and gas wells, circulating mud additive cools the bit, removes the debris, lubricates the drill pipe, closes the hole wall, controls the oil and gas pressure, and prevents the oil well from self-blowout.

Packing and Storage

25kg or 50kg bags, jumbo bags with UV Protection or according to customer’s requirement.

Specifications

Fluid Loss Control Additives—PAC-HV
Appearance White to off-white powder
pH(1 %solution) 7~8
Apparent Viscosity/AV,(mPa·s) 50min
Moisture, % 8 max
API Filtration Loss/FL(ml) ≤20

Fluid Loss Control Additives—PAC-LV
Appearance White to yellowish powder
pH(1 %solution) 7~8
Purity % 78 min

AV, Fann 35 viscometer, 600 rpm,

in fresh water

40 min
4% NaCI 38 min
Saturated NaCI 43 min
API Filtrate Loss, R.T. ml 10 max

Xanthan Gum-- UNIVIS-TEC
Appearance Light yellow free flowing powder
Specific gravity 1.45-1.55
Viscosity (1%KCl solution, mpa.s) 1200min
pH (1% in water) 5.5-8.0
Moisture 12% max
HTHP FL, mL 25.0 max
Rheological (1.0g UNIVIS-TEC @ 350ml sea water, Fann) :

600rpm............................................................ 80min

300rpm............................................................55min

200rpm............................................................45min

100rpm............................................................35min

6rpm............................................................ 17min

3rpm............................................................ 16min


API Premium Bentonite-- VF-21
Physical appearance light yellow
Moisture (@105℃,2hrs) 5%max
Fineness through 200 mesh 92%min
Loss on Ignition ( @1000℃ ) 35%max
Bulk density >420kg/m3

Barite—WA-01
Items Specification
CAS NO 1302-78-9
Appearance White
BaSO4, % 88,min
Ca,ppm 3,max
Hg,ppm 1,max
S.G:g/cm3 4.2,min
Size:200mesh,% 97min
